Toyota RAV4 IV (facelift 2015) 2.5 (176 Hp) AWD Automatic technical specifications and fuel economy

Toyota  RAV4 IV (facelift 2015)  2.5 (176 Hp) AWD Automatic

Toyota RAV4 IV (facelift 2015) 2.5 (176 Hp) AWD Automatic has a combined fuel consumption of 9.4-9.8 l/100 km urban fuel consumption of 10.7 l/100 km | 22.0 mpg US | 26.4 mpg UK extra urban fuel consumption of 8.4 l/100 km | 28.0 mpg US | 33.6 mpg UK



Toyota RAV4 IV (facelift 2015) 2.5 (176 Hp) AWD Automatic Technical information

  • Engine displacement
    2494 cm3
  • Power
    176 hp
    129 kW
  • Acceleration from 0 to 100 km/h
    N/A
  • Maximum speed
    N/A
  • Kerb Weight
    1619-1647 kg
Compare this car with other cars
Toyota  RAV4 IV (facelift 2015)  2.5 (176 Hp) AWD Automatic  General information General information
Brand : Toyota
Model : RAV4
Generation : RAV4 IV (facelift 2015)
Engine / modification : 2.5 (176 Hp) AWD Automatic
Production start : 2016 year
Production end : 2018 year
Coupe type : SUV
Num. of Doors : 5
Num. of seats : 5
Toyota  RAV4 IV (facelift 2015)  2.5 (176 Hp) AWD Automatic  Fuel economy (consumption) Fuel economy (consumption)
Fuel consumption / economy - urban : 10.7 l/100 km | 22.0 mpg US | 26.4 mpg UK
Fuel consumption / economy - extra urban : 8.4 l/100 km | 28.0 mpg US | 33.6 mpg UK
Fuel consumption / economy - combined : 9.4-9.8 l/100 km
Fuel consumption at Low speed (WLTP) :
Fuel Type : Petrol (Gasoline)
Fuel consumption at Medium speed (WLTP) :
Fuel consumption at high speed (WLTP) :
Fuel tank volume : 60 l | 15.9 US gallons | 13.2 UK gallons
Fuel consumption at very high speed (WLPT) :
Combined fuel consumption (WPLT) :
Toyota  RAV4 IV (facelift 2015)  2.5 (176 Hp) AWD Automatic  Performance Performance
Power : 176 hp | 129 kW
Max power in : 6000 rpm.
Maximum speed :
Acceleration from 0 to 100 km/h :
CO2 emissions (WLTP) :
Torque : 233 Nm @ 4100 rpm.
Toyota  RAV4 IV (facelift 2015)  2.5 (176 Hp) AWD Automatic  Engine Engine
Model Engine : 2AR-FE
Engine position : Front, transversely
Engine displacement : 2494 cm3
Engine oil capacity : 4.4 l
Coolant : 6.8 l
Fuel System : Multi-point injection
Position of cylinders : Inline
Valvetrain : DOHC, VVT-i
Number of cylinders : 4
Number of valves per cylinder : 4
Compression ratio : 10.4
Piston Stroke : 98 mm
Cylinder Bore : 89.9 mm
All-electric range (WLTP) :
Average Energy consumption (WLTP) :
Toyota  RAV4 IV (facelift 2015)  2.5 (176 Hp) AWD Automatic  Electric motor Electric motor
System power :
System torque :
Toyota  RAV4 IV (facelift 2015)  2.5 (176 Hp) AWD Automatic  Transmission Transmission
Wheel Drive : All wheel drive (4x4)
Number of Gears (automatic transmission) : 6
Toyota  RAV4 IV (facelift 2015)  2.5 (176 Hp) AWD Automatic  Chassis Chassis
Length : 4661 mm | 183.5 in
Width : 1844 mm | 72.6 in
Height : 1704-1715 mm
Wheelbase : 2659 mm | 104.7 in
Front track : 1560-1570 mm
Rear (Back) track : 1560-1570 mm
Ride height : 155 mm | 6.1 in
Approach angle : 28 °
Departure angle : 20 °
Minimum volume of Luggage (trunk) : 1087 l
Maximum amount of Luggage (trunk) : 2078 l
Front suspension : Independent, Spring McPherson, with stabilizer
Rear suspension : Double wishbone
Max weight : 2105 kg | 4641 lbs
Front brakes : Ventilated discs
Rear brakes : Disc
Kerb Weight : 1619-1647 kg
ABS : yes
Steering type : Steering rack
Power steering : Electric Steering
Minimum turning circle (turning diameter) : 10.6-11.2 m
Permitted trailer load with brakes (12%) : 680 kg
Toyota  RAV4 IV (facelift 2015)  2.5 (176 Hp) AWD Automatic  Tyres / Wheels Tyres / Wheels
Tire size : 225/65 R17; 235/55 R18
Wheel rims size : 6.5J x 17; 7.5J x 18
