Toyota RAV4 III (XA30, facelift 2011) 2.0 VVT-i (158 Hp) 4WD Multidrive technical specifications and fuel economy

Toyota  RAV4 III (XA30, facelift 2011)  2.0 VVT-i (158 Hp) 4WD Multidrive

Toyota RAV4 III (XA30, facelift 2011) 2.0 VVT-i (158 Hp) 4WD Multidrive has a combined fuel consumption of 6.5 l/100 km | 36.2 mpg US | 43.5 mpg UK urban fuel consumption of 9.6 l/100 km | 24.5 mpg US | 29.4 mpg UK extra urban fuel consumption of 6.5 l/100 km | 36.2 mpg US | 43.5 mpg UK Toyota RAV4 III (XA30, facelift 2011) 2.0 VVT-i (158 Hp) 4WD Multidrive accelerates from 0 to 100 km/h in 11.0 sec. The maximum speed is 185 km/h | 115 mph.


Toyota RAV4 III (XA30, facelift 2011) 2.0 VVT-i (158 Hp) 4WD Multidrive Technical information

Toyota  RAV4 III (XA30, facelift 2011)  2.0 VVT-i (158 Hp) 4WD Multidrive  General information General information
Brand : Toyota
Model : RAV4
Generation : RAV4 III (XA30, facelift 2011)
Engine / modification : 2.0 VVT-i (158 Hp) 4WD Multidrive
Production start : 2011 year
Production end : 2013 year
Coupe type : SUV
Num. of Doors : 5
Num. of seats : 5
Toyota  RAV4 III (XA30, facelift 2011)  2.0 VVT-i (158 Hp) 4WD Multidrive  Fuel economy (consumption) Fuel economy (consumption)
Fuel consumption / economy - urban : 9.6 l/100 km | 24.5 mpg US | 29.4 mpg UK
Fuel consumption / economy - extra urban : 6.5 l/100 km | 36.2 mpg US | 43.5 mpg UK
Fuel consumption / economy - combined : 6.5 l/100 km | 36.2 mpg US | 43.5 mpg UK
Fuel consumption at Low speed (WLTP) :
Fuel Type : Petrol (Gasoline)
Fuel consumption at Medium speed (WLTP) :
Fuel consumption at high speed (WLTP) :
Fuel tank volume : 60 l | 15.9 US gallons | 13.2 UK gallons
Fuel consumption at very high speed (WLPT) :
Combined fuel consumption (WPLT) :
Emission standard : EURO V
CO2 emissions : 177 g/km
Toyota  RAV4 III (XA30, facelift 2011)  2.0 VVT-i (158 Hp) 4WD Multidrive  Performance Performance
Power : 158 hp | 116 kW
Max power in : 6200 rpm.
Maximum speed : 185 km/h | 115 mph
Acceleration from 0 to 100 km/h : 11.0 sec
CO2 emissions (WLTP) :
Torque : 198 Nm @ 4000 rpm.
Toyota  RAV4 III (XA30, facelift 2011)  2.0 VVT-i (158 Hp) 4WD Multidrive  Engine Engine
Model Engine : 3ZR-FAE
Engine position : Front, transversely
Engine displacement : 1998 cm3
Engine oil capacity :
Fuel System : Multi-point injection
Position of cylinders : Inline
Valvetrain : DOHC, VVT-i
Number of cylinders : 4
Number of valves per cylinder : 4
Compression ratio : 9.8
Piston Stroke : 86 mm
Cylinder Bore : 86 mm
Average Energy consumption (WLTP) :
Toyota  RAV4 III (XA30, facelift 2011)  2.0 VVT-i (158 Hp) 4WD Multidrive  Electric motor Electric motor
System power :
System torque :
Toyota  RAV4 III (XA30, facelift 2011)  2.0 VVT-i (158 Hp) 4WD Multidrive  Transmission Transmission
Wheel Drive : All wheel drive (4x4)
Number of Gears (automatic transmission) : Multidrive S
Toyota  RAV4 III (XA30, facelift 2011)  2.0 VVT-i (158 Hp) 4WD Multidrive  Chassis Chassis
Length : 4365 mm | 171.9 in
Width : 1815 mm | 71.5 in
Height : 1685 mm | 66.3 in
Wheelbase : 2560 mm | 100.8 in
Ride height : 191 mm | 7.5 in
Approach angle : 28 °
Departure angle : 24 °
Ramp angle : 20 °
Wading depth : 300 mm
Minimum volume of Luggage (trunk) : 586 l
Maximum amount of Luggage (trunk) : 1752 l
Front suspension : Independent, Spring McPherson, with stabilizer
Rear suspension : Double wishbone
Max weight : 2110 kg | 4652 lbs
Front brakes : Ventilated discs
Rear brakes : Disc
Kerb Weight : 1580 kg | 3483 lbs
ABS : yes
Steering type : Steering rack
Max. roof load : 100 kg
Permitted trailer load with brakes (12%) : 1500 kg
Minimum turning circle (turning diameter) : 11.0 m
Permitted trailer load without brakes : 750 kg
All-electric range (WLTP) :
Permitted towbar download : 60 kg
Toyota  RAV4 III (XA30, facelift 2011)  2.0 VVT-i (158 Hp) 4WD Multidrive  Tyres / Wheels Tyres / Wheels
Tire size : 225/65 R17
Wheel rims size : 6.5J x 17
