Car technical specifications and fuel economy / consumption / mpg

Hyundai Santa Fe III 2.2 CRDi (197 Hp) technical specifications and fuel economy

Hyundai  Santa Fe III  2.2 CRDi (197 Hp)

Hyundai Santa Fe III 2.2 CRDi (197 Hp) has a combined fuel consumption of 5.7 l/100 km | 41.3 mpg US | 49.6 mpg UK urban fuel consumption of 7.3 l/100 km | 32.2 mpg US | 38.7 mpg UK extra urban fuel consumption of 4.7 l/100 km | 50.0 mpg US | 60.1 mpg UK Hyundai Santa Fe III 2.2 CRDi (197 Hp) accelerates from 0 to 100 km/h in 9.8 sec. The maximum speed is 190 km/h | 118 mph.



Hyundai Santa Fe III 2.2 CRDi (197 Hp) Technical information

  • Engine displacement
    2199 cm3
  • Power
    197 hp
    145 kW
  • Acceleration from 0 to 100 km/h
    9.8 sec
  • Maximum speed
    190 km/h
    118 mph
  • Kerb Weight
    1770 kg
    3902 lbs
Compare this car with other cars
Hyundai  Santa Fe III  2.2 CRDi (197 Hp)  General information General information
Brand : Hyundai
Model : Santa Fe
Generation : Santa Fe III
Engine / modification : 2.2 CRDi (197 Hp)
Production start : 2013 year
Production end : 2015 year
Coupe type : SUV
Num. of Doors : 5
Num. of seats : 7
Hyundai  Santa Fe III  2.2 CRDi (197 Hp)  Fuel economy (consumption) Fuel economy (consumption)
Fuel consumption / economy - urban : 7.3 l/100 km | 32.2 mpg US | 38.7 mpg UK
Fuel consumption / economy - extra urban : 4.7 l/100 km | 50.0 mpg US | 60.1 mpg UK
Fuel consumption / economy - combined : 5.7 l/100 km | 41.3 mpg US | 49.6 mpg UK
Fuel Type : Diesel
Fuel tank volume : 64 l | 16.9 US gallons | 14.1 UK gallons
Emission standard : Euro 5
Hyundai  Santa Fe III  2.2 CRDi (197 Hp)  Performance Performance
Power : 197 hp | 145 kW
Max power in : 3800 rpm.
Maximum speed : 190 km/h | 118 mph
Acceleration from 0 to 100 km/h : 9.8 sec
Torque : 421 Nm @ 1800-2500 rpm.
Hyundai  Santa Fe III  2.2 CRDi (197 Hp)  Engine Engine
Engine position : Front, transverse
Engine displacement : 2199 cm3
Fuel System : Diesel Commonrail
Aspiration / Turbine : Turbo / Intercooler (Turbocharging / Intercooler)
Position of cylinders : Inline
Valvetrain : DOHC
Number of cylinders : 4
Number of valves per cylinder : 4
Compression ratio : 16
Piston Stroke : 96 mm
Cylinder Bore : 85.4 mm
Hyundai  Santa Fe III  2.2 CRDi (197 Hp)  Transmission Transmission
Wheel Drive : Front wheel drive
Number of Gears (manual transmission) : 6
Hyundai  Santa Fe III  2.2 CRDi (197 Hp)  Chassis Chassis
Length : 4690 mm | 184.6 in
Width : 1880 mm | 74.0 in
Height : 1680 mm | 66.1 in
Wheelbase : 2700 mm | 106.3 in
Front track : 1633 mm | 64.3 in
Rear (Back) track : 1644 mm | 64.7 in
Minimum volume of Luggage (trunk) : 585 l
Maximum amount of Luggage (trunk) : 1570 l
Front suspension : Independent type McPherson
Rear suspension : Independent, spring
Max weight : 2510 kg | 5534 lbs
Front brakes : Ventilated discs
Rear brakes : Disc
Kerb Weight : 1770 kg | 3902 lbs
ABS : yes
Steering type : Steering rack and pinion
Power steering : Electric Steering
Minimum turning circle (turning diameter) : 10.9 m
Hyundai  Santa Fe III  2.2 CRDi (197 Hp)  Tyres / Wheels Tyres / Wheels
Tire size : 235/65 R17; 235/60 R18; 235/55 R19
Wheel rims size : 7.0J x 17; 7.5J x 18; 7.5J x 19
