Hyundai Grand Santa Fe (facelift 2016) 2.2 CRDI (200 Hp) AWD Automatic 7 Seat technical specifications and fuel economy

Hyundai  Grand Santa Fe (facelift 2016)  2.2 CRDI (200 Hp) AWD Automatic 7 Seat

Hyundai Grand Santa Fe (facelift 2016) 2.2 CRDI (200 Hp) AWD Automatic 7 Seat has a combined fuel consumption of 7.0 l/100 km | 33.6 mpg US | 40.4 mpg UK urban fuel consumption of 8.3 l/100 km | 28.3 mpg US | 34.0 mpg UK extra urban fuel consumption of 6.3 l/100 km | 37.3 mpg US | 44.8 mpg UK Hyundai Grand Santa Fe (facelift 2016) 2.2 CRDI (200 Hp) AWD Automatic 7 Seat accelerates from 0 to 100 km/h in 9.9 sec. The maximum speed is 201 km/h | 125 mph.


Hyundai Grand Santa Fe (facelift 2016) 2.2 CRDI (200 Hp) AWD Automatic 7 Seat Technical information

Hyundai  Grand Santa Fe (facelift 2016)  2.2 CRDI (200 Hp) AWD Automatic 7 Seat  General information General information
Brand : Hyundai
Model : Santa FE
Generation : Grand Santa Fe (facelift 2016)
Engine / modification : 2.2 CRDI (200 Hp) AWD Automatic 7 Seat
Production start : 2016 year
Production end : 2018 year
Coupe type : SUV
Num. of Doors : 5
Num. of seats : 7
Hyundai  Grand Santa Fe (facelift 2016)  2.2 CRDI (200 Hp) AWD Automatic 7 Seat  Fuel economy (consumption) Fuel economy (consumption)
Fuel consumption / economy - urban : 8.3 l/100 km | 28.3 mpg US | 34.0 mpg UK
Fuel consumption / economy - extra urban : 6.3 l/100 km | 37.3 mpg US | 44.8 mpg UK
Fuel consumption / economy - combined : 7.0 l/100 km | 33.6 mpg US | 40.4 mpg UK
Fuel consumption at Low speed (WLTP) :
Fuel Type : Diesel
Fuel consumption at Medium speed (WLTP) :
Fuel consumption at high speed (WLTP) :
Fuel tank volume : 71 l | 18.8 US gallons | 15.6 UK gallons
Fuel consumption at very high speed (WLPT) :
Combined fuel consumption (WPLT) :
Emission standard : Euro 6
CO2 emissions : 184 g/km
Hyundai  Grand Santa Fe (facelift 2016)  2.2 CRDI (200 Hp) AWD Automatic 7 Seat  Performance Performance
Power : 200 hp | 147 kW
Max power in : 3800 rpm.
Maximum speed : 201 km/h | 125 mph
Acceleration from 0 to 100 km/h : 9.9 sec
CO2 emissions (WLTP) :
Torque : 440 Nm @ 1750-2750 rpm.
Hyundai  Grand Santa Fe (facelift 2016)  2.2 CRDI (200 Hp) AWD Automatic 7 Seat  Engine Engine
Engine position :
Engine displacement : 2199 cm3
Engine oil capacity :
Fuel System : Diesel Commonrail
Aspiration / Turbine : Turbocharger / Intercooler
Position of cylinders : Inline
Number of cylinders : 4
Number of valves per cylinder : 4
Piston Stroke : 96 mm
Cylinder Bore : 85.4 mm
Average Energy consumption (WLTP) :
Hyundai  Grand Santa Fe (facelift 2016)  2.2 CRDI (200 Hp) AWD Automatic 7 Seat  Electric motor Electric motor
System power :
System torque :
Hyundai  Grand Santa Fe (facelift 2016)  2.2 CRDI (200 Hp) AWD Automatic 7 Seat  Transmission Transmission
Wheel Drive : All wheel drive (4x4)
Number of Gears (automatic transmission) : 6
Hyundai  Grand Santa Fe (facelift 2016)  2.2 CRDI (200 Hp) AWD Automatic 7 Seat  Chassis Chassis
Length : 4905 mm | 193.1 in
Width : 1885 mm | 74.2 in
Height : 1695 mm | 66.7 in
Wheelbase : 2800 mm | 110.2 in
Front track : 1628 mm | 64.1 in
Rear (Back) track : 1639 mm | 64.5 in
Ride height : 180 mm | 7.1 in
Front overhang : 955 mm
Rear overhang : 1150 mm
Minimum volume of Luggage (trunk) : 634 l
Maximum amount of Luggage (trunk) : 1842 l
Front suspension : Independent, Spring McPherson, with stabilizer
Rear suspension : Multi-link independent
Max weight : 2630 kg | 5798 lbs
Front brakes : Ventilated discs
Rear brakes : Disc
Kerb Weight : 1920-2057 kg
ABS : yes
Steering type : Steering rack
Power steering : Electric Steering
Max. roof load : 100 kg
Permitted trailer load with brakes (12%) : 2000 kg
Permitted trailer load without brakes : 750 kg
All-electric range (WLTP) :
Permitted towbar download : 100 kg
Hyundai  Grand Santa Fe (facelift 2016)  2.2 CRDI (200 Hp) AWD Automatic 7 Seat  Tyres / Wheels Tyres / Wheels
Tire size : 235/60 R18; 235/55 R19
Wheel rims size : 7.5J x 18; 7.5J x 19
