Ford S-MAX II (facelift 2019) 2.5 (190 Hp) Hybrid CVT 7 Seat
Car technical specifications and fuel economy / consumption / mpg

Ford S-MAX II (facelift 2019) 2.5 (190 Hp) Hybrid CVT 7 Seat technical specifications and fuel economy

Ford  S-MAX II (facelift 2019)  2.5 (190 Hp) Hybrid CVT 7 Seat

Ford S-MAX II (facelift 2019) 2.5 (190 Hp) Hybrid CVT 7 Seat accelerates from 0 to 100 km/h in 9.8 sec. The maximum speed is 185 km/h | 115 mph.



Ford S-MAX II (facelift 2019) 2.5 (190 Hp) Hybrid CVT 7 Seat Technical information

  • Engine displacement
    2488 cm3
  • Power
    150 hp
    110 kW
  • Acceleration from 0 to 100 km/h
    9.8 sec
  • Maximum speed
    185 km/h
    115 mph
  • Kerb Weight
    1872 kg
    4127 lbs
Compare this car with other cars
Ford  S-MAX II (facelift 2019)  2.5 (190 Hp) Hybrid CVT 7 Seat  General information General information
Brand : Ford
Model : S-MAX
Generation : S-MAX II (facelift 2019)
Engine / modification : 2.5 (190 Hp) Hybrid CVT 7 Seat
Production start : 2021 year
Production end :
Coupe type : MPV
Num. of Doors : 5
Num. of seats : 7
Ford  S-MAX II (facelift 2019)  2.5 (190 Hp) Hybrid CVT 7 Seat  Fuel economy (consumption) Fuel economy (consumption)
Fuel consumption / economy - urban :
Fuel consumption / economy - extra urban :
Fuel consumption / economy - combined :
Fuel consumption at Low speed (WLTP) :
Fuel Type : Petrol (Gasoline)
Fuel consumption at Medium speed (WLTP) :
Fuel consumption at high speed (WLTP) :
Fuel tank volume : 65 l | 17.2 US gallons | 14.3 UK gallons
Fuel consumption at very high speed (WLPT) :
Combined fuel consumption (WPLT) : 6.4 l/100 km
Emission standard : Euro 6d-ISC-FCM
Ford  S-MAX II (facelift 2019)  2.5 (190 Hp) Hybrid CVT 7 Seat  Performance Performance
Power : 150 hp | 110 kW
Max power in :
Maximum speed : 185 km/h | 115 mph
Acceleration from 0 to 100 km/h : 9.8 sec
CO2 emissions (WLTP) : 146-147 g/km
Torque : 200 Nm
Ford  S-MAX II (facelift 2019)  2.5 (190 Hp) Hybrid CVT 7 Seat  Engine Engine
Engine position :
Engine displacement : 2488 cm3
Engine oil capacity :
Fuel System :
Position of cylinders : Inline
Valvetrain : DOHC, VCT
Number of cylinders : 4
Number of valves per cylinder : 4
Compression ratio : 13
Piston Stroke : 100 mm
Cylinder Bore : 89 mm
All-electric range (WLTP) :
Average Energy consumption (WLTP) :
Ford  S-MAX II (facelift 2019)  2.5 (190 Hp) Hybrid CVT 7 Seat  Electric motor Electric motor
Electric motor power : 133
Battery capacity : 1.1 kWh
System power : 190 Hp @ 5 hp/ rpm.
System torque : 200 Nm Nm/ rpm.
Ford  S-MAX II (facelift 2019)  2.5 (190 Hp) Hybrid CVT 7 Seat  Transmission Transmission
Wheel Drive : Front wheel drive
Number of Gears (automatic transmission) : CVT
Ford  S-MAX II (facelift 2019)  2.5 (190 Hp) Hybrid CVT 7 Seat  Chassis Chassis
Length : 4804 mm | 189.1 in
Width : 1916 mm | 75.4 in
Width with mirrors folded : 1953 mm | 76.9 in
Width including mirrors : 2137 mm | 84.1 in
Height : 1684-1710 mm
Wheelbase : 2850 mm | 112.2 in
Front track : 1606 mm | 63.2 in
Rear (Back) track : 1606 mm | 63.2 in
Ride height : 140 mm | 5.5 in
Minimum volume of Luggage (trunk) : 185 l
Maximum amount of Luggage (trunk) : 2020 l
Front suspension : Independent, Spring McPherson, with stabilizer
Rear suspension : Independent, spring multi-link with stabilizer
Max weight : 2545 kg | 5611 lbs
Kerb Weight : 1872 kg | 4127 lbs
Steering type : Steering rack
Power steering : Electric Steering
Max. roof load : 75 kg
Minimum turning circle (turning diameter) : 11.95 m
Permitted trailer load with brakes (12%) : 1560 kg
Permitted trailer load without brakes : 750 kg
Ford  S-MAX II (facelift 2019)  2.5 (190 Hp) Hybrid CVT 7 Seat  Tyres / Wheels Tyres / Wheels
Tire size : 235/55 R17; 235/50 R18; 245/45 R19
Wheel rims size : 7.5J x 17; 7.5J x 18; 8J x 19
