Ford Ranger IV Double Cab Raptor 3.0 EcoBoost V6 (292 Hp) 4x4 Automatic technical specifications and fuel economy

Ford Ranger IV Double Cab Raptor 3.0 EcoBoost V6 (292 Hp) 4x4 Automatic

Ford Ranger IV Double Cab Raptor 3.0 EcoBoost V6 (292 Hp) 4x4 Automatic has a combined fuel consumption of 13.8 l/100 km | 17.0 mpg US | 20.5 mpg UK Ford Ranger IV Double Cab Raptor 3.0 EcoBoost V6 (292 Hp) 4x4 Automatic accelerates from 0 to 100 km/h in 7.9 sec. The maximum speed is 180 km/h | 112 mph.



Ford Ranger IV Double Cab Raptor 3.0 EcoBoost V6 (292 Hp) 4x4 Automatic Technical information

  • Engine displacement
    2956 cm3
  • Power
    292 hp
    215 kW
  • Acceleration from 0 to 100 km/h
    7.9 sec
  • Maximum speed
    180 km/h
    112 mph
  • Kerb Weight
    2454 kg
    5410 lbs
Compare this car with other cars
Ford Ranger IV Double Cab Raptor 3.0 EcoBoost V6 (292 Hp) 4x4 Automatic General information General information
Brand : Ford
Model : Ranger
Generation : Ranger IV Double Cab
Engine / modification : Raptor 3.0 EcoBoost V6 (292 Hp) 4x4 Automatic
Production start : 2022 year
Production end :
Coupe type : Pick-up
Powertrain Architecture : Internal Combustion engine
Num. of Doors : 4
Num. of seats : 5
Ford Ranger IV Double Cab Raptor 3.0 EcoBoost V6 (292 Hp) 4x4 Automatic Fuel economy (consumption) Fuel economy (consumption)
Fuel consumption / economy - urban :
Fuel consumption / economy - extra urban :
Fuel consumption / economy - combined : 13.8 l/100 km | 17.0 mpg US | 20.5 mpg UK
Fuel Type : Petrol (Gasoline)
Fuel tank volume : 80 l | 21.1 US gallons | 17.6 UK gallons
CO2 emissions : 315 g/km
Ford Ranger IV Double Cab Raptor 3.0 EcoBoost V6 (292 Hp) 4x4 Automatic Performance Performance
Power : 292 hp | 215 kW
Max power in : 5500 rpm.
Maximum speed : 180 km/h | 112 mph
Acceleration from 0 to 100 km/h : 7.9 sec
Torque : 491 Nm @ 2300 rpm.
Ford Ranger IV Double Cab Raptor 3.0 EcoBoost V6 (292 Hp) 4x4 Automatic Engine Engine
Engine position : Front, longitudinal
Engine displacement : 2956 cm3
Engine oil capacity : 6.6 l
Fuel System : Direct injection
Position of cylinders : V engine
Valvetrain : DOHC
Number of cylinders : 6
Number of valves per cylinder : 4
Compression ratio : 10.5
Piston Stroke : 86 mm
Cylinder Bore : 85.4 mm
Ford Ranger IV Double Cab Raptor 3.0 EcoBoost V6 (292 Hp) 4x4 Automatic Transmission Transmission
Wheel Drive : All wheel drive (4x4)
Ford Ranger IV Double Cab Raptor 3.0 EcoBoost V6 (292 Hp) 4x4 Automatic Chassis Chassis
Length : 5360 mm | 211.0 in
Width :
Width with mirrors folded : 2208 mm | 86.9 in
Width including mirrors : 2028 mm | 79.8 in
Height : 1926 mm | 75.8 in
Wheelbase : 3270 mm | 128.7 in
Front track : 1710 mm | 67.3 in
Rear (Back) track : 1710 mm | 67.3 in
Ride height(clearance) : 265 mm | 10.4 in
Approach angle : 32 °
Departure angle : 24 °
Front overhang : 865 mm
Rear overhang : 1225 mm
Wading depth : 850 mm
Front suspension : Double wishbone
Max weight : 3130 kg | 6900 lbs
Kerb Weight : 2454 kg | 5410 lbs
Steering type : Steering rack and pinion
Power steering : Electric Steering
Max. roof load : 80 kg
Minimum turning circle (turning diameter) : 13 m
Permitted trailer load with brakes (12%) : 2500 kg
Ford Ranger IV Double Cab Raptor 3.0 EcoBoost V6 (292 Hp) 4x4 Automatic Tyres / Wheels Tyres / Wheels
Tire size : 285/70 R17
Wheel rims size : 8.5J x 17
