Citroen Xsara Picasso (N68, Phase II) 2.0 HDi (90 Hp) technical specifications and fuel economy

Citroen  Xsara Picasso (N68, Phase II)  2.0 HDi (90 Hp)

Citroen Xsara Picasso (N68, Phase II) 2.0 HDi (90 Hp) has a combined fuel consumption of 5.5 l/100 km | 42.8 mpg US | 51.4 mpg UK urban fuel consumption of 7 l/100 km | 33.6 mpg US | 40.4 mpg UK extra urban fuel consumption of 4.6 l/100 km | 51.1 mpg US | 61.4 mpg UK Citroen Xsara Picasso (N68, Phase II) 2.0 HDi (90 Hp) accelerates from 0 to 100 km/h in 14.5 sec. The maximum speed is 175 km/h | 109 mph.



Citroen Xsara Picasso (N68, Phase II) 2.0 HDi (90 Hp) Technical information

  • Engine displacement
    1997 cm3
  • Power
    90 hp
    66 kW
  • Acceleration from 0 to 100 km/h
    14.5 sec
  • Maximum speed
    175 km/h
    109 mph
  • Kerb Weight
    1300 kg
    2866 lbs
Compare this car with other cars
Citroen  Xsara Picasso (N68, Phase II)  2.0 HDi (90 Hp)  General information General information
Brand : Citroen
Model : Xsara
Generation : Xsara Picasso (N68, Phase II)
Engine / modification : 2.0 HDi (90 Hp)
Production start : 2004 year
Production end : 2005 year
Coupe type : Minivan
Powertrain Architecture : Internal Combustion engine
Num. of Doors : 5
Num. of seats : 5
Citroen  Xsara Picasso (N68, Phase II)  2.0 HDi (90 Hp)  Fuel economy (consumption) Fuel economy (consumption)
Fuel consumption / economy - urban : 7 l/100 km | 33.6 mpg US | 40.4 mpg UK
Fuel consumption / economy - extra urban : 4.6 l/100 km | 51.1 mpg US | 61.4 mpg UK
Fuel consumption / economy - combined : 5.5 l/100 km | 42.8 mpg US | 51.4 mpg UK
Fuel Type : Diesel
Fuel tank volume : 60 l | 15.9 US gallons | 13.2 UK gallons
Emission standard : Euro 3
CO2 emissions : 147 g/km
Citroen  Xsara Picasso (N68, Phase II)  2.0 HDi (90 Hp)  Performance Performance
Power : 90 hp | 66 kW
Max power in : 4000 rpm.
Maximum speed : 175 km/h | 109 mph
Acceleration from 0 to 100 km/h : 14.5 sec
Torque : 205 Nm @ 1900 rpm.
Citroen  Xsara Picasso (N68, Phase II)  2.0 HDi (90 Hp)  Engine Engine
Model Engine : RHY DW10TD
Engine position : Front, transverse
Engine displacement : 1997 cm3
Engine oil capacity : 4.5 l
Coolant : 5.8 l
Fuel System : Diesel Commonrail
Aspiration / Turbine : Turbocharger
Position of cylinders : Inline
Valvetrain : OHC
Number of cylinders : 4
Number of valves per cylinder : 2
Compression ratio : 18
Piston Stroke : 88 mm
Cylinder Bore : 85 mm
Citroen  Xsara Picasso (N68, Phase II)  2.0 HDi (90 Hp)  Transmission Transmission
Wheel Drive : Front wheel drive
Citroen  Xsara Picasso (N68, Phase II)  2.0 HDi (90 Hp)  Chassis Chassis
Length : 4276 mm | 168.3 in
Width : 1751 mm | 68.9 in
Width including mirrors : 2000 mm | 78.7 in
Height : 1637 mm | 64.4 in
Wheelbase : 2760 mm | 108.7 in
Front track : 1434 mm | 56.5 in
Rear (Back) track : 1452 mm | 57.2 in
Front overhang : 838 mm
Rear overhang : 678 mm
Minimum volume of Luggage (trunk) : 550 l
Maximum amount of Luggage (trunk) : 2128 l
Max weight : 1850 kg | 4079 lbs
Front brakes : Ventilated discs
Rear brakes : Disc
Kerb Weight : 1300 kg | 2866 lbs
Steering type : Steering rack and pinion
Power steering : Hydraulic Steering
Max. roof load : 80 kg
Permitted trailer load with brakes (8%) : 1300 kg
Minimum turning circle (turning diameter) : 12 m
Permitted trailer load with brakes (12%) : 1300 kg
Permitted trailer load without brakes : 685 kg
Permitted towbar download : 80 kg
Citroen  Xsara Picasso (N68, Phase II)  2.0 HDi (90 Hp)  Tyres / Wheels Tyres / Wheels
Tire size : 185/65 R15
Wheel rims size : 6J x 15
