Car technical specifications and fuel economy / consumption / mpg

Chrysler Voyager VI 3.6 Pentastar V6 (291 Hp) TorqueFlite technical specifications and fuel economy

Chrysler  Voyager VI  3.6 Pentastar V6 (291 Hp) TorqueFlite


Chrysler Voyager VI 3.6 Pentastar V6 (291 Hp) TorqueFlite Technical information

Chrysler  Voyager VI  3.6 Pentastar V6 (291 Hp) TorqueFlite  General information General information
Brand : Chrysler
Model : Voyager
Generation : Voyager VI
Engine / modification : 3.6 Pentastar V6 (291 Hp) TorqueFlite
Production start : 2019 year
Production end :
Coupe type : Minivan
Num. of Doors : 5
Num. of seats : 7-8
Chrysler  Voyager VI  3.6 Pentastar V6 (291 Hp) TorqueFlite  Fuel economy (consumption) Fuel economy (consumption)
Fuel consumption / economy - urban :
Fuel consumption / economy - extra urban :
Fuel consumption / economy - combined :
Fuel consumption at Low speed (WLTP) :
Fuel Type : Petrol (Gasoline)
Fuel consumption at Medium speed (WLTP) :
Drag coefficient : 0.30
Fuel consumption at high speed (WLTP) :
Fuel tank volume : 71.9 l | 19.0 US gallons | 15.8 UK gallons
Fuel consumption at very high speed (WLPT) :
Combined fuel consumption (WPLT) :
Chrysler  Voyager VI  3.6 Pentastar V6 (291 Hp) TorqueFlite  Performance Performance
Power : 291 hp | 214 kW
Max power in : 6400 rpm.
Maximum speed :
Acceleration from 0 to 100 km/h :
CO2 emissions (WLTP) :
Torque : 355 Nm @ 4000 rpm.
Chrysler  Voyager VI  3.6 Pentastar V6 (291 Hp) TorqueFlite  Engine Engine
Engine position :
Engine displacement : 3605 cm3
Engine oil capacity : 4.7 l
Coolant : 6.8 l
Fuel System :
Maximum engine speed : 6400 rpm.
Position of cylinders : V engine
Valvetrain : CVVT
Number of cylinders : 6
Number of valves per cylinder : 4
Compression ratio : 11.3
Piston Stroke : 83 mm
Cylinder Bore : 96 mm
Average Energy consumption (WLTP) :
Chrysler  Voyager VI  3.6 Pentastar V6 (291 Hp) TorqueFlite  Electric motor Electric motor
System power :
System torque :
Chrysler  Voyager VI  3.6 Pentastar V6 (291 Hp) TorqueFlite  Transmission Transmission
Wheel Drive : Front wheel drive
Number of Gears (automatic transmission) : 9 TorqueFlite
Chrysler  Voyager VI  3.6 Pentastar V6 (291 Hp) TorqueFlite  Chassis Chassis
Length : 5176 mm | 203.8 in
Width : 2022 mm | 79.6 in
Width including mirrors : 2297 mm | 90.4 in
Height : 1777 mm | 70.0 in
Wheelbase : 3089 mm | 121.6 in
Front track : 1735 mm | 68.3 in
Rear (Back) track : 1736 mm | 68.3 in
Ride height : 131 mm | 5.2 in
Approach angle : 14 °
Departure angle : 18.7 °
Ramp angle : 12.5 °
Front overhang : 960 mm
Rear overhang : 1127 mm
Minimum volume of Luggage (trunk) : 915 l
Maximum amount of Luggage (trunk) : 3979 l
Front suspension : Independent, Spring McPherson, with stabilizer
Rear suspension : Independent, spring
Max weight : 2747 kg | 6056 lbs
Front brakes : Ventilated discs
Rear brakes : Disc
Kerb Weight : 1964 kg | 4330 lbs
ABS : yes
Steering type : Steering rack
Power steering : Electric Steering
Minimum turning circle (turning diameter) : 12.1 m
All-electric range (WLTP) :
Chrysler  Voyager VI  3.6 Pentastar V6 (291 Hp) TorqueFlite  Tyres / Wheels Tyres / Wheels
Tire size : 235/65 R17
Wheel rims size : 7J x 17
