BMW X1 (U11) 23d (211 Hp) MHEV sDrive Steptronic technical specifications and fuel economy
BMW X1 (U11) 23d (211 Hp) MHEV sDrive Steptronic accelerates from 0 to 100 km/h in 7.4 sec. The maximum speed is 225 km/h | 140 mph.
BMW X1 (U11) 23d (211 Hp) MHEV sDrive Steptronic Technical information
|
|
General information
|
|
|---|---|
| Brand : | BMW |
| Model : | X1 |
| Generation : | X1 (U11) |
| Engine / modification : | 23d (211 Hp) MHEV sDrive Steptronic |
| Production start : | 2022 year |
| Production end : | |
| Coupe type : | |
| Powertrain Architecture : | MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV) |
| Num. of Doors : | 5 |
| Num. of seats : | 5 |
Fuel economy (consumption)
|
|
| Fuel consumption / economy - urban : | |
| Fuel consumption / economy - extra urban : | |
| Fuel consumption / economy - combined : | |
| Fuel Type : | Diesel |
| Drag coefficient : | 0.27 |
| Fuel tank volume : | 45 l | 11.9 US gallons | 9.9 UK gallons |
| Combined fuel consumption (WLTP) : | 4.8-5.3 l/100 km |
| Emission standard : | Euro 6d |
Performance
|
|
| Power : | 197 hp | 145 kW |
| Max power in : | 4000 rpm. |
| Maximum speed : | 225 km/h | 140 mph |
| Acceleration from 0 to 100 km/h : | 7.4 sec |
| CO2 emissions (WLTP) : | 125-140 g/km |
| Torque : | 400 Nm @ 1500-2750 rpm. |
Engine
|
|
| Engine position : | Front, transverse |
| Engine displacement : | 1995 cm3 |
| Engine oil capacity : | 6.5 l |
| Fuel System : | Diesel Commonrail |
| Position of cylinders : | Inline |
| Valvetrain : | DOHC |
| Number of cylinders : | 4 |
| Number of valves per cylinder : | 4 |
| Compression ratio : | 16.5 |
| Piston Stroke : | 90 mm |
| Cylinder Bore : | 84 mm |
Electric motor
|
|
| Electric motor power : | 19 |
| Electric motor Torque : | 55 Nm |
| Battery voltage : | 48 V |
| Battery technology : | Lithium-ion (Li-Ion) |
| System power : | 211 Hp hp/ rpm. |
| System torque : | 400 Nm Nm/ rpm. |
Transmission
|
|
| Wheel Drive : | Front wheel drive |
| Number of Gears (automatic transmission) : | 7 Steptronic |
Chassis
|
|
| Length : | 4500 mm | 177.2 in |
| Width : | 1845 mm | 72.6 in |
| Width including mirrors : | 2104 mm | 82.8 in |
| Height : | 1642 mm | 64.6 in |
| Wheelbase : | 2692 mm | 106.0 in |
| Front track : | 1592 mm | 62.7 in |
| Rear (Back) track : | 1593 mm | 62.7 in |
| Ride height(clearance) : | 205 mm | 8.1 in |
| Front overhang : | 875 mm |
| Rear overhang : | 933 mm |
| Minimum volume of Luggage (trunk) : | 500 l |
| Maximum amount of Luggage (trunk) : | 1545 l |
| Front suspension : | Independent, Spring McPherson, with stabilizer |
| Rear suspension : | Multi-link independent |
| Max weight : | 2265 kg | 4993 lbs |
| Front brakes : | Ventilated discs |
| Rear brakes : | Disc |
| Kerb Weight : | 1690 kg | 3726 lbs |
| Steering type : | Steering rack and pinion |
| Power steering : | Electric Steering |
| Max. roof load : | 75 kg |
| Minimum turning circle (turning diameter) : | 11.7 m |
| Permitted trailer load with brakes (12%) : | 2000 kg |
| Permitted trailer load without brakes : | 750 kg |
| Permitted towbar download : | 80 kg |
Tyres / Wheels
|
|
| Tire size : | 205/65 R17 |
| Wheel rims size : | 7J x 17 |
