Volkswagen  Passat Variant (B8)  2.0 TDI (150 Hp) 4MOTION

Volkswagen Passat Variant (B8) 2.0 TDI (150 Hp) 4MOTION Technical specifications and fuel economy

Volkswagen Passat Variant (B8) 2.0 TDI (150 Hp) 4MOTION has a combined fuel consumption of 4.7-4.6 l/100 km. urban fuel consumption of 5.7-5.6 l/100 km. extra urban fuel consumption of 4.1-4.0 l/100 km. Volkswagen Passat Variant (B8) 2.0 TDI (150 Hp) 4MOTION accelerates from 0 to 100 km/h in 8.9 sec. The maximum speed is 213 km/h | 132 mph.


Volkswagen Passat Variant (B8) 2.0 TDI (150 Hp) 4MOTION Technical information

Volkswagen  Passat Variant (B8)  2.0 TDI (150 Hp) 4MOTION  General information General information
Brand : Volkswagen
Model : Passat
Generation : Passat Variant (B8)
Engine / modification : 2.0 TDI (150 Hp) 4MOTION
Production start : 2014 year
Production end :
Coupe type : Combi
Num. of Doors : 5
Num. of seats : 5
Volkswagen  Passat Variant (B8)  2.0 TDI (150 Hp) 4MOTION  Fuel economy (consumption) Fuel economy (consumption)
Fuel consumption / economy - urban : 5.7-5.6 l/100 km.
Fuel consumption / economy - extra urban : 4.1-4.0 l/100 km.
Fuel consumption / economy - combined : 4.7-4.6 l/100 km.
Fuel Type : Diesel
Fuel tank volume : 66 l | 17.4 US gallons | 14.5 UK gallons
Emission standard : EURO VI
CO2 emissions : 123-120 g/km
Volkswagen  Passat Variant (B8)  2.0 TDI (150 Hp) 4MOTION  Performance Performance
Power : 150 hp | 110 kW
Max power in : 3500-4000 rpm.
Maximum speed : 213 km/h | 132 mph
Acceleration from 0 to 100 km/h : 8.9 sec
Torque : 340 Nm/1750-3000 rpm.
Volkswagen  Passat Variant (B8)  2.0 TDI (150 Hp) 4MOTION  Engine Engine
Engine position : Front, transversely
Engine displacement : 1968 cm3
Engine oil capacity :
Fuel System : Diesel Commonrail
Aspiration / Turbine : Turbo / Intercooler (Turbocharging / Intercooler)
Position of cylinders : Inline
Number of cylinders : 4
Number of valves per cylinder : 4
Volkswagen  Passat Variant (B8)  2.0 TDI (150 Hp) 4MOTION  Transmission Transmission
Wheel Drive : All wheel drive (4x4)
Number of Gears (manual transmission) : 6
Volkswagen  Passat Variant (B8)  2.0 TDI (150 Hp) 4MOTION  Chassis Chassis
Length : 4767 mm. | 187.7 in
Width : 1832 mm. | 72.1 in
Width including mirrors : 2083 mm. | 82.0 in
Height : 1477 mm. | 58.1 in
Wheelbase : 2791 mm. | 109.9 in
Front track : 1584 mm. | 62.4 in
Rear (Back) track : 1568 mm. | 61.7 in
Ride height : 145 mm. | 5.7 in
Minimum volume of Luggage (trunk) : 650 l
Maximum amount of Luggage (trunk) : 1780 l
Front suspension : Independent multi-link
Rear suspension : Independent, spring
Max weight : 2220 kg. | 4894 lbs
Kerb Weight : 1556 kg. | 3430 lbs
Front brakes : Ventilated discs
Rear brakes : Disc
ABS : yes
Steering type : Steering rack
Power steering : Electric Steering
Max. roof load : 100 kg.
Permitted trailer load with brakes (8%) : 2200 kg.
Permitted trailer load with brakes (12%) : 2200 kg.
Minimum turning circle (turning diameter) : 11.7 m
Permitted trailer load without brakes : 750 kg.
Permitted towbar download : 90 kg.
Volkswagen  Passat Variant (B8)  2.0 TDI (150 Hp) 4MOTION  Tyres / Wheels Tyres / Wheels
Tire size : 215/55 R17; 235/45 R18; 235/40 R19
Wheel rims size : 7J x 17; 8J x 18; 8J x 19
