Seat  Altea XL (facelift 2009)  1.6 TDI (90 Hp)

Seat Altea XL (facelift 2009) 1.6 TDI (90 Hp) Technical specifications and fuel economy

Seat Altea XL (facelift 2009) 1.6 TDI (90 Hp) has a combined fuel consumption of 4.8 l/100 km. | 49.0 mpg US | 58.9 mpg UK urban fuel consumption of 5.9 l/100 km. | 39.9 mpg US | 47.9 mpg UK extra urban fuel consumption of 4.2 l/100 km. | 56.0 mpg US | 67.3 mpg UK Seat Altea XL (facelift 2009) 1.6 TDI (90 Hp) accelerates from 0 to 100 km/h in 14.1 sec. The maximum speed is 172 km/h | 107 mph.


Seat Altea XL (facelift 2009) 1.6 TDI (90 Hp) Technical information

Seat  Altea XL (facelift 2009)  1.6 TDI (90 Hp)  General information General information
Brand : Seat
Model : Altea
Generation : Altea XL (facelift 2009)
Engine / modification : 1.6 TDI (90 Hp)
Production start : 2010 year
Production end :
Coupe type : MPV
Num. of Doors : 5
Num. of seats : 5
Seat  Altea XL (facelift 2009)  1.6 TDI (90 Hp)  Fuel economy (consumption) Fuel economy (consumption)
Fuel consumption / economy - urban : 5.9 l/100 km. | 39.9 mpg US | 47.9 mpg UK
Fuel consumption / economy - extra urban : 4.2 l/100 km. | 56.0 mpg US | 67.3 mpg UK
Fuel consumption / economy - combined : 4.8 l/100 km. | 49.0 mpg US | 58.9 mpg UK
Fuel Type : Diesel
Fuel tank volume : 55 l | 14.5 US gallons | 12.1 UK gallons
Emission standard : EURO V
CO2 emissions : 126 g/km
Seat  Altea XL (facelift 2009)  1.6 TDI (90 Hp)  Performance Performance
Power : 90 hp | 66 kW
Max power in : 4200 rpm.
Maximum speed : 172 km/h | 107 mph
Acceleration from 0 to 100 km/h : 14.1 sec
Torque : 230 Nm/1500-2500 rpm.
Seat  Altea XL (facelift 2009)  1.6 TDI (90 Hp)  Engine Engine
Engine position : Front, transversely
Engine displacement : 1598 cm3
Engine oil capacity :
Fuel System : Diesel Commonrail
Aspiration / Turbine : Turbo / Intercooler (Turbocharging / Intercooler)
Position of cylinders : Inline
Number of cylinders : 4
Number of valves per cylinder : 4
Compression ratio : 16.5
Stroke : 80.5 mm.
Bore : 79.5 mm.
Seat  Altea XL (facelift 2009)  1.6 TDI (90 Hp)  Transmission Transmission
Wheel Drive : Front wheel drive
Number of Gears (manual transmission) : 5
Seat  Altea XL (facelift 2009)  1.6 TDI (90 Hp)  Chassis Chassis
Length : 4469 mm. | 175.9 in
Width : 1768 mm. | 69.6 in
Height : 1581 mm. | 62.2 in
Wheelbase : 2578 mm. | 101.5 in
Front track : 1527-1541 mm.
Rear (Back) track : 1503-1517 mm.
Minimum volume of Luggage (trunk) : 532 l
Front suspension : Independent, Spring McPherson, with stabilizer
Rear suspension : Multi-link independent
Max weight : 2029 kg. | 4473 lbs
Kerb Weight : 1485 kg. | 3274 lbs
Front brakes : Ventilated discs
Rear brakes : Disc
ABS : yes
Steering type : Steering rack
Minimum turning circle (turning diameter) : 10.7 m
Seat  Altea XL (facelift 2009)  1.6 TDI (90 Hp)  Tyres / Wheels Tyres / Wheels
Tire size : 195/65 R15 91H; 205/55 R16 91V; 225/45 R17 91W; 225/40 R18 92Y
Wheel rims size : 6J x 15-ET47; 6.5J x 16-ET50; 7J x 17 -ET54; 7.5J x 18-ET51
