Car technical specifications and fuel economy / consumption / mpg
Hyundai  Sonata VI (YF)  2.4 (209 Hp) Hybrid Automatic

Hyundai Sonata VI (YF) 2.4 (209 Hp) Hybrid Automatic Technical specifications and fuel economy

Hyundai Sonata VI (YF) 2.4 (209 Hp) Hybrid Automatic has a combined fuel consumption of 6.5 l/100 km. | 36.2 mpg US | 43.5 mpg UK

Hyundai Sonata VI (YF) 2.4 (209 Hp) Hybrid Automatic Technical information

Hyundai  Sonata VI (YF)  2.4 (209 Hp) Hybrid Automatic  General information General information
Brand : Hyundai
Model : Sonata
Generation : Sonata VI (YF)
Engine / modification : 2.4 (209 Hp) Hybrid Automatic
Production start : 2010 year
Production end : 2012 year
Coupe type : Sedan
Num. of Doors : 4
Num. of seats : 5
Hyundai  Sonata VI (YF)  2.4 (209 Hp) Hybrid Automatic  Fuel economy (consumption) Fuel economy (consumption)
Fuel consumption / economy - urban :
Fuel consumption / economy - extra urban :
Fuel consumption / economy - combined : 6.5 l/100 km. | 36.2 mpg US | 43.5 mpg UK
Fuel Type : Hybrid - petrol / electricity
Drag coefficient : 0.25
Fuel tank volume : 65 l | 17.2 US gallons | 14.3 UK gallons
Hyundai  Sonata VI (YF)  2.4 (209 Hp) Hybrid Automatic  Performance Performance
Power : 209 hp | 154 kW
Max power in :
Maximum speed :
Acceleration from 0 to 100 km/h :
Torque :
Hyundai  Sonata VI (YF)  2.4 (209 Hp) Hybrid Automatic  Engine Engine
Engine position : Front, transversely
Engine displacement : 2359 cm3
Engine oil capacity :
Fuel System : Multi-point injection
Position of cylinders : Inline
Valvetrain : DOHC, CVVT
Number of cylinders : 4
Number of valves per cylinder : 4
Compression ratio : 13
Piston Stroke : 97 mm.
Cylinder Bore : 88 mm.
Hyundai  Sonata VI (YF)  2.4 (209 Hp) Hybrid Automatic  Electric motor Electric motor
Electric motor power : 41
Electric motor Torque : 205 /1400 rpm. Nm
Battery capacity : 1.43 kWh
ICE Torque : 209 Nm/4500 rpm.
ICE power : 168 hp
Hyundai  Sonata VI (YF)  2.4 (209 Hp) Hybrid Automatic  Transmission Transmission
Wheel Drive : Front wheel drive
Number of Gears (automatic transmission) : 6
Hyundai  Sonata VI (YF)  2.4 (209 Hp) Hybrid Automatic  Chassis Chassis
Length : 4820 mm. | 189.8 in
Width : 1835 mm. | 72.2 in
Height : 1470 mm. | 57.9 in
Wheelbase : 2795 mm. | 110.0 in
Front track : 1597 mm. | 62.9 in
Rear (Back) track : 1597 mm. | 62.9 in
Minimum volume of Luggage (trunk) : 303 l
Front suspension : Independent, Spring McPherson, with stabilizer
Rear suspension : Multi-link independent
Max weight :
Kerb Weight : 1580 kg. | 3483 lbs
Front brakes : Ventilated discs
Rear brakes : Ventilated discs
ABS : yes
Steering type : Steering rack
Minimum turning circle (turning diameter) : 10.9 m
Hyundai  Sonata VI (YF)  2.4 (209 Hp) Hybrid Automatic  Tyres / Wheels Tyres / Wheels
Tire size : 205/65 R16
Wheel rims size : 6.5J × 16
